DW-PW114YZ Ticket Wing Gate

prevnext

Features
Using high-quality 304 stainless steel stamping forming, beautiful and generous, anti-rust and durable;
Standard equipment: main controller, rotating mechanism controller, two-dimensional bar code reader, VFD high-brightness display, traffic indicator, voice module, power module;
The single-wing wing gate and the double-wing wing gate can be combined into ticket checking units with different number of channels;
When the aisle is opened, the wing plate is fully received inside the gate, and the aisle is unobstructed, which is more intuitive and more convenient for people to pass;
High-precision sensor group and intelligent identification algorithm design, 6 groups of infrared detection sensor electric eyes are arranged in the channel, which can well identify the number and direction of personnel in the channel, greatly improving the accuracy of anti-trap and anti-trailing;
Multi-point detection, more suitable for children or people carrying luggage;
Intelligent voice and sound effect prompts, with "please pass the gate, please check tickets, do not stay in the channel, do not go backwards, welcome to come again" and other smart voice and sound effect prompts, making the device more user-friendly and easier to use;
Can add fingerprint comparison module, ID card recognition module, portrait and notice display module, single / two-way channel switching module.
Using industrial-grade embedded ARM main control board.
The wing panel is embedded with metal brackets and flame-retardant polyurethane foam material is opened and molded, which is not only strong and durable, but also has good contact and flexibility;
Automatically recover the wing panel after power off, and automatically close the door when power is on, which meets the fire protection requirements;
It can cooperate with Dongwo series of ticket checking machines to realize multi-function ticket checking such as barcode, QR code, RFID, IC card, fingerprint, second-generation ID card, portrait monitoring, etc .;
The standard configuration:
QR code metal keyboard display
Optional:
RFID (IC card), ID card, fingerprint, camera, etc.
Dimensions:
Length 1400mm × width 280mm × height 980mm
weight:
70 (KG)
Channel width
600MM
Traffic direction:
Bidirectional, unidirectional (optional)
Working mode of brake lever:
Fully automatic brushless motor drive
Light tips:
Direction indication
Working movement:
German technology, Taiwan Taibang brushless motor
Adopt optical working principle, no delay requirement for input control signal
Control board with counting function, LED digital display function (optional)
working environment:
Indoor and outdoor
temperature:
-20 ℃ ∽50 ℃
Emergency measures:
Power off automatically
Card reader port:
Comes with standard mounting bracket, or customized
Opening time:
0.1-0.2 seconds
Passing speed:
Maximum: 45 ~ 50 people / minute Average: 35 ~ 40 people / minute
input interface:
+ 12V level signal or DC12V pulse signal with pulse width> 100ms, drive current> 10mA; dry contact signal (relay open signal) standard RS485 interface
